Short Description:

1.Product Detail 1-1 Quick Details Condition:New Type: Injection Molding Style: Horizontal Brand Name: UKD Model Number:ZX-260 Place of Origin:Zhejiang, China (Mainland) Plastic Type: Thermoplastic Automatic: Yes Injection Weight: 490-700g Injection Rate: 55-91g/s Clamping Force: 2600KN Opening Stroke: 550mm Power(KW): 22 Certification: CE ISO9001 After-sales Service Provided: Engineers available to service machinery overseas Voltage: 380V/ 50Hz 3P+...


  • FOB Price: US $10,000~400,000
  • Min.Order Quantity: 1set
  • Supply Ability: 100 sets per Month
  • Port: Ningbo port
  • Payment Terms: L/C,D/A,D/P,T/T
  • Product Detail

    FAQ

    Specification

    Product Tags

    1.Product Detail

    1-1 Quick Details

    Condition:New

    Type: Injection Molding

    Style: Horizontal

    Brand Name: UKD

    Model Number:ZX-260

    Place of Origin:Zhejiang, China (Mainland)

    Plastic Type: Thermoplastic

    Automatic: Yes

    Injection Weight: 490-700g

    Injection Rate: 55-91g/s

    Clamping Force: 2600KN

    Opening Stroke: 550mm

    Power(KW): 22

    Certification: CE ISO9001

    After-sales Service Provided: Engineers available to service machinery overseas

    Voltage: 380V/ 50Hz 3P+N+E (alterable)

    Machine weight: 8.5 ton

    Screw Diameter: 50-60mm

    Machine dimension(L*W*H): 6*1.4*2.1m

    Warranty: 1 Years



    1-2 Packaging & Delivery

    Packaging Details:

    WOOD BOTTOM  PACKAGE WITH ANTI-WATER FLIM AND

    PLASTIC BAGS

    Delivery Detail

    30~60 days





    1-3 PET Professional Machinery

    1.Screw designed according to PET material’s characteristics, breakthrough improvement on the defects of bubble, flow mark, white patch , yellowing, etc, products quality highly improved.
    2. Increased plasticizing capacity, wonderful plasticization, preform color more uniform, production more stable.
    3. Machine’s structure and spare parts optimized according to preform characteristics, product quality and efficiency is higher.
    4. Increased ejection force fit for ejecting multi cavity preform.
    5. Double-loop system can be for option, come true the simultaneous movement, production efficiency highly improved; At the same time, higher filling speed ensure products’ internal stress reduced obviously, product quality higher.
    6. Can option complete auxiliaries, such as: Dehumidified, Hopper dryer, Auto loader, Hot runner, Mold, Chiller etc.
    7. Post-Mold Cooling (PMC) is available, production capacity can be highly improved (maximum 35% higher), lessened scratch from ejection, and risk-free from clamping against inefficient ejection.

     -小标题:Small Injection molding machine ZX-260

    1.产品描述: Product Description

    标准装备                      Standard Equipment


    注塑装置                           Injection unit

    PET专用螺杆

    PET special screw and barrel design

    双杠平衡注射系统

    Double-cylinder balanced injection system

    杠座台进移

    Single-cylinder forwarder

    料筒保护罩

    Barrel protection cover

    射胶/保压/溶胶设定

    Injection/holding/plasticizing setting

    螺杆放冷启动

    Screw cold start-up prevention

    防流延功能

    Drooling prevention function

    防滑花纹铝盖板

    Injection unit anti-slip aluminum cover

    自动清料功能

    Automatic purging function

    射胶故障自动检测

    Automatic detection of injection failure

    注射位置检测功能

    Injection cushion position monitoring  function

    储料背压调节功能

    Screw plasticizing back pressure control function

    螺杆驱动液压马达

    Screw-driven hydraulic motor

    注射速度,压力控制装置

    Injection speedpressure control device










    锁模装置                                Clamping unit

    自动集中润滑系统

    Automatic centralized lubrication system

    特快锁模功能

    High speed clamping function

    多种顶针功能方式选择

    Multi stagemulti function hydraulic ejection control

    抽芯动方式选择

    Core puller operating mold

    低压模具保护装置

    Low pressure mold protection device

    开关模刹车装置

    Mechanical positive mold open position device

    可调节式动模板支撑结构

    Supported structure of the adjustable and movable device

    液压马达驱动调节装置

    Hydraulic motor drive mold adjustment device

    开关模,顶出位置控制

    Open/close mold ejection position foot control

    T型槽模板400T以下

    T-slot platen (≤400T

    机械安全装置

    Mechanical safely device

    强化处理动模板移动耐磨轨道

    Strengthen treatment of the linear motion










    液压装置                                Hydraulic unit

    高性能伺服系统

    High quality servo system

    低噪音液压控制系统

    Low-noise hydraulic control system

    邮箱液位计

    Oil level display of oil tank

    液压油冷却装置

    Oil cooler water temperature control valce

    高性能精密滤油装置

    High precision filter

    电磁阀

    Solenoid valve




    电控装置                               Electric unit

    异常原因显示功能

    Abnormal display function

    紧急停止保护装置

    Emergency stop protection

    温度偏差显示

    Temperature deviation display

    点击安全保护装置

    Motor safety protection device

    外供预留电源插头

    Outer providing and reserving power pluge

    电气硬件连锁保护功能

    Electrical hardware chain protect function

    生产周期计数

    Production counter

    异常运作警报灯

    Abnormal operation alarm light

    数据锁定功能

    Date locking function

    多种语言显示

    Multi-language display

    最高压力限制功能

    Max. pressure limited function

    中断功能

    Interrupt circuit

    料筒自动加温装置

    Automatic barrel heat-up control device

    PID温度控制器

    PID temperature controller





    其他                                   General

    标准颜色

     standard  color

    封闭式保护门设计

    Enclosure safety door design

    可调防震垫脚

    Adjustable machine leveling device

    附件箱

    Stander accessories

    常用工具

    Professional tools

    普通料斗

    Stander material hopper

    易损备件

    Easily damaged spare parts



    2:参数     Specification






    3.选购装置     Optional equipment

    加长射嘴

    Extended nozzle

    弹弓射嘴

    Spring shot-out nozzle

    油压封嘴

    Hydraulic shot-out nozzle

    混炼头加强混色效果

    Static mixer for color mixing

    特殊原料专用螺杆

    Specialized screw for the special materials

    多组吹气阀

    Multiple blow valve

    多组抽芯装置

    Multiple core puller device

    电磁感应加热装置

    Induction heater system

    加大预塑马达

    Increase pre-injection motor

    铰牙装置

    Unscrewing device

    料筒吹风装置

    Barrel blowing device

    增加容模量

    Increase mould height capacity

    回油过滤系统

    Return line filtration system

    机械手

    Robot

    自动上料机

    Auto loader

    干燥料斗

    Hopper dryer

    除湿机

    Hopper magnet

    三相电子式电能表

    Three-phaonic watt-hour meter

    模具温度控制器

    Mold temperature controller

    高性能变量泵系统

    High-preformance variable pump system

    高性能节能伺服系统

    High-preformance and energy-saving servo system

    模板隔热板

    Insulation platen

    玻璃管冷却流量器

    Glass tube cooling folwmefer/ Glass pipe cooling flow measure

    磁力架

    Magnetic frame

    模具压板

    Mold clam

    液压安全保护

    Hydraulic safety protection

    比例

    Proportional valve back pressure

    油压偏差报警功能

    Oil temperature upper lower limit alarm

    自动调节功能

    Auto-mode function
