Powerful crusher

Short Description:

  1.Feeding   hopper   2.Rotating blade frame   3.Hard wheel nut   4.Rotating blade   5.Fixed blade   6.Frame   7.truckle   8.Fixed blade   9.Strap cover 10.Motor 11.Motor wheel 12.vee belt   13.Safety switch    14.Stop switch   15.Start switch   16.Quincunx handlel   17.Flywheel   18.Wheel cover   19.Crushing room   20.Crushing room   21.Screen frame handle   22.Strop...


  • FOB Price: US $10,000~400,000
  • Min.Order Quantity: 1set
  • Supply Ability: 100 sets per Month
  • Port: Ningbo port
  • Payment Terms: L/C,D/A,D/P,T/T
  • Product Detail

    FAQ

    Specification

    Product Tags

      1.Feeding   hopper
      2.Rotating blade frame
      3.Hard wheel nut
      4.Rotating blade
      5.Fixed blade
      6.Frame
      7.truckle
      8.Fixed blade
      9.Strap cover
     10.Motor
     11.Motor wheel
     12.vee belt

      13.Safety switch
      14.Stop switch
      15.Start switch
      16.Quincunx handlel
      17.Flywheel
      18.Wheel cover
      19.Crushing room
      20.Crushing room
      21.Screen frame handle
      22.Strop cover
      23.Strop wheel
      24.Screen frame
      25.Mobile hopper

    The whole machine adopts high hardness steel template, and is soild and durable;

    Shaft made of special material processing,not easily deformed;

    Cutter can be adjusted independently,and can be sharpened with repeated use;

    Feeding hopper,cutter and filter can be separated with easy disassembling and cleaning;

    Motor is installed with overload protection and safe switches for assuring safety;

    Discharging hole technology of cone production network,greatly enhancing efficiency.

    Specification

    Model

    Grinding   chamber caliber

    (kw)

    Grinding  capacity (kw/h)

    Motor   power

    (kw)

    Qty. Of   stationary blade

    Qty. Of   rotary blade

    Size(mm)

    Weight

    (kg)

    JSCS-180F

    180*160

    100-150

    1.5/2.2

    2

    9

    630x520x

    950

    140

    JSCS-230F

    230*200

    150-200

    4.0

    2

    6

    900x640x

    1050

    250

    JSCS-300F

    300*230

    200-250

    5.5

    2

    9

    1030x750x1200

    380

    JSCS-400F

    400*245

    300-450

    7.5

    2

    12

    1100x860x1330

    550

    JSCS-500F

    500*300

    400-800

    11

    2

    15

    1300x1020x1520

    700

    JSCS-600F

    600*335

    450-900

    15

    4

    18

    1450x1150x1700

    950

    JSCS-800F

    800*500

    650-1300

    22-37

    4

    24

    1850x1410x2130

    1700

    JSCS-1000

    1000*610

    750-1500

    37-55

    4

    30

    1950x1580x2500

    2800
